MSI had its turn just before with their new Z390 motherboards led by the flagship MEG Z390 GODLIKE motherboard, but now it's time for ASUS to shine in the light with their Z390 motherboards and the flagship Z390 ROG Maximus XI.

The new ASUS Z390 ROG Maximus XI CODE motherboard with an absolutely huge heat sink that spreads from the first to second x16 PCIe port and over the Z390 chipset, edging to the 4 x DDR4 DIMM slots. It looks glorious as well, with some awesome RGB-lit start/reset buttons next the DIMMs. It requires an 8+6-pin power at the top, and is ready for the flagship Core i9-9900K processor.

This motherboard is the new ASUS Z390 ROG Maximus XI, and you can see that there's some EK Water Blocks cooling above the CPU, with the same behemoth of a heat sink on the board. Looks great IMO, even in black and white as a preview image.

Intel is getting its new 9000-series CPUs ready for launch in the next month, with motherboard makers preparing their Z390 motherboards. MSI's new Z390 range has now leaked, led by the flagship MEG Z390 GODLIKE which looks so damn awesome.

MSI's new flagship MEG Z390 GODLIKE features an M.2 expansion card as well as something else - it seems to be a streaming-related card with an HDMI port on the back so maybe this is for gamers who want to game on their Core i9-9900K as well as stream to Twitch, etc. The MZI MEG Z390 GODLIKE motherboard sports four PCIe x16 ports, three M.2 slots (and another two with the M.2 expansion card), and a larger E-ATX form factor.

Next up we have the new MSI MPG Z390 Gaming Pro Carbon AC motherboard that has tons of RGBs coming out of it - hell, all of these new Z390 motherboards from MSI do.

Intel will soon enough be unleashing its next-gen-but-kind-of-not Z390 chipset, with GIGABYTE's upcoming Z390 Gaming SLI motherboard teased courtesy of VideoCardz.

As you can see, the Z390 Gaming SLI motherboard has one of its PCIe x1 slots upgraded to a x16 port allowing for two NVIDIA GeForce graphics cards to be installed in SLI. We're not looking at GIGABYTE's highest-end motherboard, as there are some models above this before we even enter the AORUS brand.

There's a pre-installed backplate which looks slick, and less connections on the I/O which is a shame - but expected on a more mid-range motherboard. Still, it will support two of NVIDIA's next-gen GeForce RTX 2080s or RTX 2080 Ti in SLI and not break the bank (at least on the motherboard, the GPUs are an entirely new argument on price, ha).

GIGABYTE has just announced their flagship X399 motherboard that is fully prepared and laden with features ready for AMD's upcoming next-gen Ryzen Threadripper CPUs.

The new GIGABYTE X399 AORUS Extreme motherboard will support the new Threadripper 2990WX which is AMD's upcoming 32C/64T flagship second-gen TR processor that has a TDP of up to 250W. GIGABYTE is using a heavily improved cooling system on the X399 AORUS Extreme, with 10+3 phase PWM supply that gets its power through not one, but two 8-pin EPS connectors.

There are 8 x DDR4 DIMM slots on the GIGABYTE X399 AORUS Extreme, 6 x SATA 6Gbps ports, 3 x M.2 slots (which are cooled by GIGABYTE's M.2 heat sinks), 4 x PCIe 3.0 x16 slots, and 1 x PCIe 3.0 x1 slot. There's 64 PCIe lanes thanks to Threadripper, so GIGABYTE is preparing for anyone to throw the kitchen sink at this motherboard with connectivity options galore.

ASUS has just confirmed that it's working on a slew of Z390 motherboards, with a huge 19 motherboards set to be unleashed in the coming months.

There is a listing on the official ASUS website with the new Z390 motherboards to be found in the families of STRIX, Prime, TUF, and Dragon series while the flagship Maximus XI takes care of the high-end side of the market. There will be ASUS ROG Maximus XI APEX and FORMULA motherboards for overclockers, while a mini-ITX motherboard can be found in the Z390-I STRIX.

Here's the full list:

Intel is expected to launch its new Z390 chipset in the near future, but according to the latest rumors the 'new' Z390 chipset won't be so new after all... and will reportedly be a rebadged Z370 chipset.

Right now, all of Intel's current 300-series chipsets are made on the 14nm node, except for the Z370. It was expected that the refreshed Z390 chipset would be made on 14nm, but with Intel having a million troubles right now - 10nm node is busted, their CEO resigned just a few days ago - things are changing.

Z390 will reportedly not be made on the 14nm node but will be on the same 22nm node as the current Z370 chipset. This means we won't see native support for USB 3.1 Gen 2 and other technologies that would've made it into the 14nm-based Z390, so there will be third-party controllers used by motherboard makers instead.

Intel didn't unveil its new Z390 chipset during Computex 2018, but that doesn't mean it disappeared and won't be released, as the purported ASUS ROG Maximus XI motherboard has been teased.

VideoCardz is behind the new report, stating that they "finally got info from my moles at ASUS. It appears that ASUS will bump the Roman numeration for Intel's upcoming high-end chipset". The site also confirms that there will be at least four Maximus XI motherboards on their way, while confirming four ROG STRIX motherboards.

GIGABYTE teased all with their huge motherboard capable of overclocking Intel's 28-core monster CPU to 5GHz, let's see what was hiding under the heat sinks and find out more about the CPU and motherboard.

There has been a lot of chatter about Intel's debut of their 5GHz 28-core beast, and while that CPU is probably a modified Xeon Platinum 8180, Intel nor the vendors would give us any information on the CPU or even motherboard. However, we can learn a lot from the motherboard used to demo the chip to the world. For starters, let's get this out of the way; yes, that chip was without a doubt overclocked. The VRM on the motherboard is a monster, and designed to support much more than Intel's "300W" TDP number (the Platinum 8180 is rated for 205W TDP).

For reference, Intel's 18-core 7980XE can easily pull 500W when overclocked to 4.5GHz. So add the increased leakage from taking more than 50% more cores all 500MHz higher, and add to that the decrease in VRM efficiency due to increased phase count, and we think the VRM could be pulling 1.2-1.8 KW. We heard rumors of the 7980XE pulling up to 1000W under LN2, so we don't think our numbers are too far off. We also heard that Intel was hitting the limits of physics, and we aren't just talking about upgrading their circuit breakers.

ASUS has just unveiled its monster new crypto mining motherboard, with the introduction of the H370 Mining Master motherboard, which can handle 20 graphics cards for the ultimate mining motherboard.

ASUS has learned from its first B350 Mining Expert motherboard, with the new H370 Mining Master motherboard simplifying the entire mining experience by letting USB riser cables connect directly into the PCB. Glorious. This means you can run 20 graphics cards at once, without as many cables and headaches - and trust me, there are lots of headaches with super-crazy mining setups.

The H370 Mining Master motherboard has mining-specific tweaks that ASUS has performed to the board, another nice touch, with one of them being the GPU state detection before the board boots, as you can see in the image above.

Intel and AMD are preparing new chipsets that are sure to confuse customers in the coming months, with AMD planning their beefed up Z490 chipset while Intel do the same with a suped up Z390 chipset.

AMD's upcoming Z490 chipset will be very similar to the just-released Z470 chipset, except the new Z490 chipset will rock new PCIe lanes when it drops in June. We should expect an 8C/16T variant of Intel's Coffee Lake CPUs, so think the Core i7-8790K, which will debut alongside the refreshed Z390 chipset.

Intel will be keeping its HEDT chipset around for a while, with X299 staying with us through 2H 2018.

AMD is currently in the process of launching their new flagship X470 chipset with the Pinnacle Ridge-based Ryzen 2000 series processors, but now a mysterious Z490 chipset has been teased.

VideoCardz reports on a slide that was allegedly posted on the PCEva forums, where it shows a presentation of GIGABYTE's AORUS X470 motherboards, showing the differences between some of the chipsets and then the mysterious Z490 (not X490, but Z490) chipset.

The purported Z490 chipset is identical to the X470 chipset except that it rocks 4 additional PCIe 3.0 lanes, something that would be great for multi-GPU users who want PCIe lanes for precious graphics cards, and multiple super-fast NVMe M.2 SSDs that need PCIe lanes to drive their insane speeds.

BIOSTAR has accidentally leaked out Intel's upcoming Z390 chipset, with an early reveal of their own Z390 RACING GT3 and GT5 motherboards with a manual on the B360 RACING GT3S leaking and teasing the Z390 as well.

If we're seeing manuals on these motherboards, it means that the new/refreshed Z390 motherboards are imminent. The manual can even be downloaded from BIOSTAR's website, but we don't know much about the Z390 chipset at all. We do know that BIOSTAR's new motherboard has support for CPUs at up to 95W TDP, which might "indirectly confirm the maximum TDP of 8-core Coffee Lake-S CPU" according to VideoCardz.

If there was a teeny tiny Ryzen 2000-capable motherboard that wins best all-round looks, it would go to the ASUS ROG STRIX X470-I Mini-ITX, which looks awesome.

The upcoming ASUS ROG STRIX X470-I Mini-ITX is a powerhouse motherboard offering a hidden M.2 slot, two DDR4 DIMM slots, and a built-in Wi-Fi adapter.

ASUS includes the usual full-length PCIe x16 slot, so you can power your new AMD Ryzen 7 2700X with a Radeon RX Vega 64 (yeah, probably not), or a GeForce GTX 1080 Ti.

ASUS is preparing the ROG Crosshair VII motherboard with AMD's new X470 chipset, ready for the launch of the new Ryzen 2000 series CPUs that are right around the corner.

The new ASUS ROG Crosshair VII motherboard rocks a new VRM heat sink, a pre-installed I/O shield, power on/rest buttons have been moved next to the DIMM slots, while we now have a M.2 slot with a dedicated heat sink to keep those super-fast NVMe drives from getting too hot.

ASUS have changed things up between the previous-gen ROG Crosshair VI and the new ROG Crosshair VII, with the latter featuring less SATA 6Gbps ports with 6 drives capable on the new board compared to 8 on the former. The I/O bracket features 12 x USB ports (with a mix of 2.0, 3.0, and 3.1) compared to 14 on the previous-gen port, but the new board now sports a PS/2 port.

In a world that is dominated with performance and mining builds, GIGABYTE haven't forgotten about the little guy, in this case small-form factor PC's. GIGABYTE have announced the release of the new generation Gemini Lake based J/N series motherboards that feature an on-board CPU, humidity protected glass fabric PCBs, long acting capacitors, anti-surge ICs, low resistance MOSFETs, and Ultra Durable components.

"Following the announcement of the newest Intel Pentium Silver and Celeron Processors, GIGABYTE developed a series of motherboards that truly reflects our excellent ability to combine the best of motherboard technology with Intel processor architecture," GIGABYTE stated.

Powered by the latest Intel Pentium Silver and Intel Celeron processors, GIGBYTE's latest J/N series motherboards also includes support for M.2 SATA SSD, UDIMM DDR4 2400MHz memory, HDMI 2.0 4K and utilizes fanless cooling technology to provide the perfect solution for always-on, compact builds.

CES 2018 - At CES 2018, SuperMicro's subsidiary, SuperO, showed us a glimpse of their C9X299-PG300. The new C9X299-PG300 will replace any X299 motherboard we might have showed you at Computex, and will be available shortly. The new motherboard has enhanced VRM and M.2 cooling, as well as simple and straightforward aesthetics.

The motherboard's revamped VRM supports 300W TDP CPUs, and it's designed for overclocking. It features eight DDR4 DIMMs rated at up to 4000Mhz+, and you can load it up with 128GB of DDR4. The motherboard features four x16 PCI-E 3.0 slots, but bandwidth will vary depending on which CPU you use. We also find six SATA6Gb/s ports, two U.2 slots, two x4 PCI-E 3.0 M.2 lots, 10Gbit LAN, 1Gbit Intel LAN, and two customizable RGB LED headers.

CES 2018 - ASRock's commitment to the small form factor PC is unwavering, and at CECS 2018 they showed off two new Micro-ATX motherboards. The X299 chipset mainly serves Intel's X-Series of processors while the X399 chipset serves AMD's Thread Ripper CPUs. As such, they are high-end desktop chipsets loaded with features and more importantly, traces. Putting either on a micro-ATX motherboard is no easy feat, but ASRock is up to the task.

The X299M Extreme 4 offers four DIMMs for quad channel memory and support for up to 4200MHz+ DIMMs. It uses an XXL Aluminum Alloy heat sink that cools down its insane VRM. You do get SLI and CrossFireX support along with six SATA6G/s ports, two Ultra M.2 slots, two USB 3.1 ports, six USB 3.0 ports, Intel Gbit LAN, and 7.1 HD audio. ASRock also includes RGB LED capabilities.

Thread Ripper's CPU is huge, so it is quite shocking to see a micro-ATX X399 motherboard. The new motherboard supports quad channel memory support, three Ultra M.2 slots, eight SATA6Gb/s slots, a U.2 port, three x16 PCI-E 3.0 slots, 10 USB 3.0 ports, two USB 3.1 ports, dual Gbit LAN, WIFI, and 7.1 HD audio. It also uses a giant aluminum heat sink to cool down a powerful VRM, so you can overclock your stealth compact ThreadRipper rig.

CES 2018 - NZXT is mostly known for chassis and cooling solutions, but starting with the new N7 Z370, the company is getting into motherboards.

NZXT's first jump into the motherboard market comes with the N7 Z370, a $300 motherboard built on the Z370 chipset that sports a digital fan controller, RGB colors, and an all-metal frame that's specifically designed to compliment snazzy builds. The N7 Z370 comes in both black and white, and its full suite of profiles can be controlled by NZXT's CAM software, including RGB effects, fan curves, and more.

"Leveraging our years of experience as professional PC builders, we've designed the N7 motherboard with a completely new approach. In the face of increasing complexity in the PC gaming market, we want to make building easier and more enjoyable, with the N7 as a cornerstone for this new experience. Everything you need--from easy layout and obvious connections to digital fan control and RGB lighting--is included. We've also designed a completely unique motherboard cover so it's both beautiful and powerful. You can't build a quieter, better-looking system as easily as you can with our new N7 motherboard." says Johnny Hou, NZXT's founder, and CEO.

CES 2018 - GIGABYTE had a secret motherboard on hand at their CES 2018 ballroom, and we got a sneak peak so we could show you what they have in store for 2018. The AMD AM4 X470-based Aorus Gaming 7 is totally redesigned compared to their X370 Aorus Gaming 7.

The new motherboard has two M.2 slots, one routed to the CPU at x4 PCI-E 3.0 and one to the chipset at x4 PCI-E 2.0, both of them have heat sinks. The motherboard will support current and future AM4 CPUs, but should be compatible with Ryzen-2000 series CPUs/APUs out of the box.

Surprisingly, GIGABYTE decided to go back to the tried-and-true fin-type heat sink, which offers maximum cooling efficiency because of its maximized surface area. The new X470 motherboard features a 10+2 phase VRM controlled by an IR35201 PWM controller. Each power stage uses IR3553 40A PowIRstages for AMD's next gen Zen+ and current CPUs.

AMD is preparing their next-gen Ryzen processors for 2018, but we're already hearing about the new 400-series chipset that will power next-gen motherboards thanks to a new post on PCI-SIG.

The upcoming Zen+/Ryzen 2000 range is also known as Pinnacle Ridge, and will be an upgrade of Zen 1 made on 12nm. AMD will give us higher clock speeds and improved power efficiency, which is always welcomed. Zen 2 will be saved for the Ryzen 3000 series of processors, which will offer even more improvements over Zen as it will be baked onto the super-delicious 7nm node.

AMD's upcoming Summit Ridge 300 series chipset was listed on PCI-SIG in January 2016, but now we have the new codename Promontory chipset listed on PCI-SIG, which was added on December 19, 2017. This new chipset teased "AMD 400 Series Chipsets" which will include X470, B450, and A420 series motherboards.
