Synology DS415play Four Bay NAS Review

Synology DS415play Four Bay NAS Review

Today Tyler spends some time telling us all about the new four-bay DS415play NAS from Synology. If you want video streaming, this could be the one for you.

@TylerBernath
Published Wed, Aug 27 2014 1:15 AM CDT   |   Updated Tue, Apr 7 2020 12:33 PM CDT
Rating: 89%Manufacturer: Synology

Introduction & Pricing and Availability

Synology DS415play Four Bay NAS Review 01 | TweakTown.com
VIEW GALLERY - 30 IMAGES

About a month ago, Synology launched the four bay follow up to the ever popular DS214play. This new network storage solution, dubbed the DS415play, carries over the same hardware platform from the aforementioned DS214play, albeit with two more bays.

The DS415play carries on Synology's commitment to the Intel Evansport platform, including hardware transcoding via the custom ffmpeg implementation, in addition to the ability to stream 1080p to any number of devices.

The DS415play from its inception was built to be the last media server you will need. At the heart of this solution, we have the Intel CE5335 dual-core SoC, paired with 1GB of DDR3. On the rear of the unit, you will find a single gigabit Ethernet port from which Synology says you can achieve 112 MB/s read and 101 MB/s write speeds in RAID 5 within a Windows OS environment.

Being the latest from Synology, the DS415play is backed by the award winning DSM 5.0 NAS operating system. Let's continue on now and take a close look at it.

Pricing and Availability

Synology DS415play Four Bay NAS Review 02 | TweakTown.com

The specifications for the DS415play start with the dual-core Intel Atom, which operates at 1.6GHz. Moving down the list, we find hardware transcoding support for H.264, MPEG4, MPEG2 and VC-1 next to 1GB of DDR3.

Internal capacity for the DS415play peaks out at 24TB via four 6TB HDDs with additional support for EXT4, EXT3, FAT, NTFS and HFS+ via the USB 3.0 ports located on the rear of the unit.

MSRP for the Synology DS415play is listed at $569.99 with a two-year warranty.

Synology DS415play

Packaging and a Closer Look

Synology DS415play Four Bay NAS Review 03 | TweakTown.com

Packaging for the DS415play has the NAS in a brown cardboard box with a simple Synology logo across the front.

Synology DS415play Four Bay NAS Review 04 | TweakTown.com

Scope of delivery for the DS415play includes an Ethernet cable, power adapter, and reading materials.

Synology DS415play Four Bay NAS Review 05 | TweakTown.com

The front of the DS415play carries a glossy black front panel. A small portion of the front is dedicated to activity LEDs which flash green.

Synology DS415play Four Bay NAS Review 06 | TweakTown.com

The side of the unit carries an embossed panel with the company logo.

Synology DS415play Four Bay NAS Review 07 | TweakTown.com

Behind the front panel, we find four tool less drive bays. At the top each bay is numbered with dots.

Synology DS415play Four Bay NAS Review 08 | TweakTown.com

The back of the NAS houses dual 92mm cooling fans, while down below, we have dual USB 2.0 ports next to the gigabit Ethernet port, and another two USB 3.0 ports at the bottom.

NAS GUI and Test System Setup

NAS GUI

Synology DS415play Four Bay NAS Review 11 | TweakTown.com

To setup the DS415play, we entered the NAS IP into our web browser. From here, the Web Assistant guided us through setup.

Synology DS415play Four Bay NAS Review 12 | TweakTown.com

The first step for setup was to download the latest DSM from the web or navigate to a previously downloaded installation.

Synology DS415play Four Bay NAS Review 13 | TweakTown.com

We then created a password for our DSM installation and named our server.

Synology DS415play Four Bay NAS Review 15 | TweakTown.com

DSM took 10 to 15 minutes to download and install on our DS415play. Of course, your results will vary depending on your internet connection speed.

Synology DS415play Four Bay NAS Review 16 | TweakTown.com

After setup was complete, we landed at the main menu to login to our DS415play.

Synology DS415play Four Bay NAS Review 18 | TweakTown.com

The main menu for the NAS carries a rather clean appearance. At the top left, we have a few icons for shortcuts to the File Station, Control Panel and Package Center. However, mousing over to the logo in the very top left corner loads a more in depth menu.

Synology DS415play Four Bay NAS Review 19 | TweakTown.com

Expanding the corner button menu, we have options to configure storage, backups and replication, along with a resource monitor.

Test System Setup

Synology DS415play Four Bay NAS Review 100 | TweakTown.com

Our Consumer NAS test 'system' is setup similar to what you have at home. Here we have the base of a GIGABYTE Z97X UD7 TH, housing an Intel Core i7 4770 with 16GB of RAM supporting. Our operating system of choice is Windows 8 x64 Enterprise, with all available updates and patches installed on a pair of Samsung 840 SSDs.

On the networking side, we utilized the Intel PRO1000 PT Server Adapter with a direct connection to each NAS appliance. This eliminates the need for a switch, and any bottlenecks that may occur.

Benchmarks - Single Client Throughput

Workload

HD Video Play - 720p HD stream from Windows Media Player, 256kB reads

2HD Video Play - 2x playback

4HD Video Play - 4x playback

HD Video Record - 720p HD stream, 256kB writes

File Copy From NAS - 4GB file copy, 64kB reads

File Copy To NAS - 64kB writes

Synology DS415play Four Bay NAS Review 25 | TweakTown.com

Single client results for the DS415play started off with the NAS scaling through the Video Playback quite well. File copy operations to the NAS came in at 93.4 MB/s.

Synology DS415play Four Bay NAS Review 26 | TweakTown.com

RAID 5 seen the NAS take a small performance hit with peak results coming in video playback.

Synology DS415play Four Bay NAS Review 27 | TweakTown.com

RAID 10 picked up where the RAID 0 left off. Here we found results at 113 MB/s for 4x playback, while file copy operations came in at 94 MB/s to the NAS.

Benchmarks - Sequential and Mixed Workloads

Our Sequential read/write workload is centered on 128K transfer sizes; again, with sixteen threads, and a Queue Depth of 8.

Synology DS415play Four Bay NAS Review 28 | TweakTown.com

Starting off with RAID 0, the DS415play came in at 116 MB/s read and 107 MB/s write, topping the charts in both instances.

Synology DS415play Four Bay NAS Review 29 | TweakTown.com

Moving to RAID 5, the 415play came in at 79 MB/s read and 79 MB/s write.

Synology DS415play Four Bay NAS Review 30 | TweakTown.com

RAID 10 performance picked back up with 107 MB/s read and 85 MB/s write.

Mixed Workloads

Synology DS415play Four Bay NAS Review 34 | TweakTown.com

Mixed workloads showed the DS415play doing the best with Web Server at 387 IOPS.

Synology DS415play Four Bay NAS Review 35 | TweakTown.com

Moving to RAID 5, the Synology once again did quite well with Web Server at 402 IOPS.

Synology DS415play Four Bay NAS Review 36 | TweakTown.com

RAID 10 had the DS415play quicker than the TS470, but behind the TS451.

Final Thoughts

Synology DS415play Four Bay NAS Review 20 | TweakTown.com

The Synology DS415play, while being my first foray into the world of DSM, leaves a good impression. I enjoyed the layout of the Web GUI or DSM 5.0 rather. While it certainly takes some getting used to if you're moving from another NAS vendor, the ease of use goes quite far in aiding the process.

As many of you know, the big advantage of the Intel Evansport platform is the hardware transcoding feature built into the SoC. Of course, this plays into the hands of the people over at Plex, one of largest and most popular media servers available to support the feature. As of today, as you can see in the image above with CPU usage upwards of 90%, it is not supported.

Synology DS415play Four Bay NAS Review 22 | TweakTown.com

Not all is lost though, as Synology has taken the issue upon themselves and enabled a custom build of ffmpeg to allow hardware transcoding on their own platform. Judging from the image above, and the noticeable improvement on CPU usage down to 23%, we can say it works quite well.

Synology DS415play Four Bay NAS Review 37 | TweakTown.com

Performance of the DS415play was quite good, and while it didn't top the charts in all instances, we did manage to get some really good numbers from our sequential testing. Perhaps, one of the more intriguing characteristics of the DS415play is its power consumption figures. In testing, we measured a peak of 41 watts during the single client testing, while at idle the Synology unit was able to calm to a nice 25 watts at idle. Of course, this is with WD Red 4TB drives, and your results will depend severely on what hard disk drives are used.

Overall, the Synology DS415play is great solution for those wanting the option for 24TB of storage capacity, along with the ability to transcode and stream media on-the-fly at 1080p, something not all vendors in the market can provide at this point in time.
