NVIDIA's new RTX PRO 6000 Blackwell PCB with double-sided 96GB GDDR7 detailed

As an Amazon Associate, we earn from qualifying purchases. TweakTown may also earn commissions from other affiliate partners at no extra cost to you.

NVIDIA's new RTX PRO 6000 Blackwell workstation GPU has had its gorgeous PCB leaked, showing off its 96GB of double-sided GDDR7 memory, check it out:

2

The new NVIDIA RTX PRO 6000 Blackwell GPU is the flagship GB202-based workstation graphics card from the company, offered in 3 different variants leading up to 96GB of GDDR7 memory. The PCB was recently leaked onto Chiphell, giving us a gander at the amount of work that goes into a ridiculously high-end GPU with 96GB of double-sided GDDR7 memory (48GB per side).

There are no components at all on the PCB pictured -- no GPU, no GDDR7 memory modules -- but GDDR7 memory modules will be placed on both sides of the NVIDIA RTX PRO 6000 Blackwell GPU. Each GDDR7 module is 3GB, with 16 x 2 x 3GB = 96GB in total. NVIDIA could re-use this PCB for its RTX PRO 5000 with 48GB of GDDR7 (as it would use single-sided modules, not double-sided), while the RTX PRO 4500 uses 32GB of GDDR7 memory (2GB modules) and the GB203 GPU.

• Read more: NVIDIA's new RTX PRO 6000 Blackwell GPU with 96GB GDDR7 costs $8435
• Read more: NVIDIA RTX PRO 6000 Blackwell GPU: 24064 CUDA cores, 96GB GDDR7, up to 600W

The PCB shared on Chiphell appears to be of the Max-Q variant of the card, with NVIDIA limiting the power consumption to just a 300W TDP. The full RTX PRO 6000 Blackwell GPU (Workstation Edition and Server Edition) variants have the same GPU + VRAM configuration, but they allow for 600W TDPs. NVIDIA has the power connector on the rear of the RTX PRO 6000 Max-Q variant.
