University of Toronto selects CoolIT Systems to liquid cool signal processor for CHIME Project

CoolIT Systems, the world leader in energy efficient liquid cooling solutions for the HPC, Cloud and Enterprise markets, has been selected by the University of Toronto to provide custom liquid cooling for its new signal processing backend which will support Canada's largest radio telescope, the Canadian Hydrogen Intensity Mapping Experiment (CHIME), a joint project between the National Research Council of Canada (NRC) and three major Universities (McGill, Toronto, UBC).

Custom Direct Contact Liquid Cooling solution will support Canada's largest radio telescope

The system to be cooled is being housed at the NRC's facility for radio astronomy at Penticton B.C. The sealed container functions as a Faraday Cage to prevent leakage of electromagnetic energy which would contaminate the telescope's observations. The CHIME collaboration realised early in its planning process that cooling the custom GPU-intensive servers with traditional air conditioning would be difficult and costly, and began exploring liquid-cooled solutions.

In order to complete its primary cosmological mission, mapping out the largest volume of space ever attempted in a survey, CHIME requires a powerful signal processing backend, capable of sustaining real-time correlation of high-cadence radio data. Given the scale of the telescope, with 400MHz of bandwidth and 2,048 receiving elements, this requires ~8x1015 integer operations per second (~8 Pop/s) operating 24/7 on a 6.4 Tb/s input stream. All nodes must be able to operate in high ambient temperatures: up to 45C for extended periods of time.

CoolIT Systems custom Rack DCLC implementation will provide a net cooling effect on room temperature. The liquid cooled system will consist of 256 rack-mounted General Technics GT0180 custom 4u servers housed in 26 racks managed by CoolIT Systems Rack DCLC CHx40 Heat Exchanger Modules. The custom direct contact cooling loops will manage 100% of heat generated by the single Intel Xeon E5 2620v3 CPUs and the Dual AMD FirePro S9300x2 GPUs, while simultaneously pulling heat from the ambient air into the liquid coolant loops.

"We chose to work with CoolIT Systems because their solutions are modular and robust, and as a result the most flexible and efficient for our situation," says Keith Vanderlinde, Assistant Professor at the University of Toronto. "With the custom liquid cooling solution, we can drastically reduce CHIME's energy consumption and squeeze additional processing out of the GPUs."

"Our success with CHIME proves that our solutions are truly versatile, and that diverse HPC scenarios can increase their efficiency through the advantage of liquid cooling systems," comments CoolIT Systems CEO Geoff Lyon about the company's first experience cooling the computing system for a radio telescope. "We look forward to similarly unique installations in the future, and to continuing to work on less-traditional HPC cooling challenges," he concluded.

The liquid cooling installation's estimated completion date is early 2017.

About CoolIT Systems, Inc.

CoolIT Systems Inc. is a world leader in Direct Contact Liquid Cooling (DCLCÃÆ'Ã,¢"Ã,Ã,¢) for the Data Center, Server and Desktop markets. As an experienced innovator with 50 patents and more than 2 million liquid cooling units deployed, CoolIT brings a wealth of design, engineering, and manufacturing knowledge to the table. CoolIT's Rack DCLCÃÆ'Ã,¢"Ã,Ã,¢ platform is a modular, rack-based, advanced cooling solution that allows for dramatic increases in rack densities, component performance, and power efficiencies. The technology can be deployed with any server and in any rack making it a truly flexible solution that allows for an edge in today's highly competitive marketplace.

About CHIME

The Canadian Hydrogen Intensity Mapping Experiment (CHIME) is a radio telescope composed of four 20m x 100m parabolic cylindrical reflectors, each with 256 dual-polarization radio receiving elements. The system will map out the entire northern sky each day, aiming to constrain the properties and evolution of Dark Energy over a broad swath of cosmic history.
