GIGABYTE Radeon HD 7790 1GB OC Overclocked Video Card Review

GIGABYTE Radeon HD 7790 1GB OC Overclocked Video Card Review
With a new GPU model from AMD we're got some different versions of the new Radeon HD 7790 and today we look at one from GIGABYTE and overclock it.
| AMD Radeon GPU in Video Cards | Posted: Mar 26, 2013 4:56 am
TweakTown Rating: 90%Manufacturer: GIGABYTE

Introduction



TweakTown image content/5/2/5288_02_gigabyte_radeon_hd_7790_1gb_oc_overclocked_video_card_review.jpg



While GIGABYTE is a name we hear a lot about at TweakTown when it comes to the motherboards, it's been over a year since we've looked at a video card from the company. Today, though, we've got a chance to look at the new Radeon HD 7790 that AMD has just released from GIGABYTE to see just what they've been up to since we last crossed paths.



At launch we looked at the Sapphire HD 7790 1GB Dual-X and found ourselves impressed with what AMD was offering with the new GPU and what Sapphire had done with it. Since that was an OC model and today the GIGABYTE video card we're looking at also is an OC model, we've decided to look at the overclocking side of things.



It will be interesting to see what goes on with performance when it comes to overclocking, but as always there are a few things that we need to do before we've got a chance to do that. The first thing we'll take a look at is the box and the bundle that GIGABYTE is offering. From there we'll move onto the video card itself to see what kind of cooler setup is on offer.



From the card we'll get into the specification side of things where we'll cover the out of the box clock speeds along with the overclock speeds that we managed to achieve. Finally we'll take a look at our testbed, cover the cards that you'll see in our graphs today and finally see what's going on with performance with the overclocked GIGABYTE HD 7790.





Package



TweakTown image content/5/2/5288_03_gigabyte_radeon_hd_7790_1gb_oc_overclocked_video_card_review.jpg



While it's been a while since we've seen a GIGABYTE video card, not much has changed on the package side of things. You can see we've got the model on the front along with some of the main features which include the core overclock, the fan they're using and the amount of memory.



TweakTown image content/5/2/5288_04_gigabyte_radeon_hd_7790_1gb_oc_overclocked_video_card_review.jpg



Turning over to the back of the box you can see we've got a run down on the fan which is one of the main features. You can also see mention that we're on a 28nm core, have PCIe 3.0 support along with some of the main features in a number of languages.



TweakTown image content/5/2/5288_05_gigabyte_radeon_hd_7790_1gb_oc_overclocked_video_card_review.jpg



As we move inside the box we've got a fairly standard mid-range bundle from GIGABYTE here. Along with the Quick Guide and driver CD, you can also see we've got a dual Molex to 6-pin PCIe power connector.
