MSI X299 Gaming M7 ACK Motherboard Review

MSI X299 Gaming M7 ACK Motherboard Review

MSI's new X299 Gaming M7 ACK motherboard ticks many of the boxes we look for, especially in the quality department. Should you buy it? Let's see.

@StevenBassiriTT
Steven Bassiri
Published Wed, Aug 2 2017 11:55 AM CDT   |   Updated Thu, Jul 30 2020 4:20 PM CDT
Rating: 90%Manufacturer: MSI

Introduction, Specifications, and Pricing

MSI X299 Gaming M7 ACK Motherboard Review 01 | TweakTown.com
VIEW GALLERY - 97 IMAGES

MSI's X299 Gaming M7 ACK is a bigger and badder X299 motherboard than the previous X299 Gaming Pro Carbon AC we reviewed. The M7 ACK is actually one of MSI's top of the line X299 motherboards, with a reinvented M.2 shield and a plethora of other premium features.

The motherboard is mainly targeting gamers, but it's also targeted towards modders and power users. It offers the latest features such as RGB LEDs, M.2, and USB 3.1, but it also offers a lot regarding aesthetics and even some overclocking features.

Let's take a look at one of MSI's top of the line X299 motherboards.

Specifications

MSI X299 Gaming M7 ACK Motherboard Review 02 | TweakTown.com

The X299 Gaming M7 ACK features two M.2 slots, U.2, Killer wireless AC, Killer LAN, USB 3.1, USB 3.0, and SATA6Gb/s.

Pricing

The X299 Gaming M7 ACK costs $399.99.

Packaging and X299 Gaming M7 ACK Overview

Packaging and Overview

MSI X299 Gaming M7 ACK Motherboard Review 03 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 04 | TweakTown.com

It's really quite amazing how vendors are sticking to their traditional box and motherboard design styles. On the shelf, you might not notice the difference between the Z270 and X299 Gaming M7 ACK. Packaging is high quality, and what you would expect from a motherboard that costs almost $400.

MSI X299 Gaming M7 ACK Motherboard Review 05 | TweakTown.com

The accessory package includes four SATA6Gb/s cables, two WIFI Antenna, RGB LED extension cable, IO shield, 3D Mounting screws, SLI HB bridge, base badge, manuals, cable sticker, and driver DVD.

MSI X299 Gaming M7 ACK Motherboard Review 06 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 07 | TweakTown.com

The motherboard features a total of six hybrid PWM/DC mode fan headers. The ones circled in red provide up to 1A of output while the one circled in blue offers 2A for water pumps and high-powered fans. Overall, the placement of the fan headers is optimized for top and bottom fan placement, although I find it odd that MSI didn't locate any headers to the far right of the board. Fan control is provided through the UEFI and Windows, and MSI has improved it over their Z270 fan control. The back of the motherboard is bare of most components, which is a good thing. The motherboard's aesthetics are quite well done, with the integrated RGB LEDs diffusing and glowing beneath many of the heat sinks.

MSI X299 Gaming M7 ACK Motherboard Review 08 | TweakTown.com

The IO panel offers a Clear CMOS button, BIOS flash recovery button, PS/2, three USB 2.0 ports (vertical doubles for flash recovery), WIFI antenna, four USB 3.0, USB 3.1 type-A, USB 3.1 type-C, 1Gbit LAN, and 7.1 audio outputs with S/PDIF out.

MSI X299 Gaming M7 ACK Motherboard Review 09 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 10 | TweakTown.com

The PCI-E layout isn't simple, so I will explain it now, and you should look at the manual for more specifics. All x16 slots are routed to the CPU while the two x1 are routed to the PCH. With a 44-lane CPU, the second x16 slot operates at x4 all the time, while at maximum you get x16/x4/x16/x8. With a 28-lane CPU the second x16 slot also operates at x4 always, and at a maximum you get x8/x4/x8/x8. With a 16-lane CPU, you lose the bottom most slot and can operate at x8/x4/x4 or x8/x0/x8 at a maximum. The motherboard offers 8+4 pin power headers, you don't need to use the extra 4, but it's recommended.

MSI X299 Gaming M7 ACK Motherboard Review 11 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 12 | TweakTown.com

MSI got a lot of grief for their original M.2 shield, as people said it was way too skinny. MSI went back to the drawing board and has brought out one of my favorite M.2 shields. It actually uses a hinge and connects to the PCH heat sink, it's also quite dense and does seem to offer decent cooling. The motherboard offers two 32Gb/s M.2 slots, and they do share some bandwidth with the SATA ports.

MSI X299 Gaming M7 ACK Motherboard Review 13 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 14 | TweakTown.com

The motherboard has eight SATA6Gb/s ports; six are right angled. The motherboard also offers a U.2 port, and a right angled USB 3.0 internal header. You also get one straight USB 3.0 internal header as well as the new USB 3.1 internal header.

MSI X299 Gaming M7 ACK Motherboard Review 15 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 16 | TweakTown.com

A POST Code display changes into a temperature display after POST has finished. The motherboard also offers boot LEDs and voltage read points in the top right corner of the motherboard. The other two SATA6Gb/s ports are angled straight up near the OC Knob. Power and reset buttons can be found below a BIOS selection switch. The VROC header is located to the left of the power button.

MSI X299 Gaming M7 ACK Motherboard Review 17 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 18 | TweakTown.com

The motherboard offers two USB 2.0 headers as well as a bunch of other headers to do things like engage slow-mode on the CPU. An RGB LED header is located to the left of three system fan headers at the bottom of the motherboard.

MSI X299 Gaming M7 ACK Motherboard Review 19 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 20 | TweakTown.com

The PCH heat sink's dragon lights up beautifully and is one of my favorite parts of the motherboard. All heat sinks use thermal pads and make great contact with the different components they cool.

MSI X299 Gaming M7 ACK Circuit Analysis

Circuit Analysis

MSI X299 Gaming M7 ACK Motherboard Review 21 | TweakTown.com

The X299 Gaming M7 ACK in the nude!

MSI X299 Gaming M7 ACK Motherboard Review 22 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 23 | TweakTown.com

The VRM on the motherboard for the CPU main voltage is 10 phases (5 doubled), and one more phase is for the VCCSA. All the main and VCCSA phases use IR's 60A IR3555 Fully integrated power stages and an IR35201 6+2 phase PWM is used in 5+1 phase mode.

MSI X299 Gaming M7 ACK Motherboard Review 24 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 25 | TweakTown.com

Five IR3599 doublers/quadrouplers are used to double the 5 PWM rails to 10 for the main VCore/input voltage. The VRM here is identical to that on the X299 Gaming Pro Carbon AC. A single IR352014 (3+1 phase) PWM controls a single phase made up of a CSD87350Q NexFET (25/40A) and uses a Chil CHL8510 driver to drive the dual N-channel MOSFET.

MSI X299 Gaming M7 ACK Motherboard Review 26 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 27 | TweakTown.com

Each memory VRM uses a Primarion PV4210 digital PWM, Primarion and IR are both owned by Infineon, and both PWMs are top of the line digital PWMs. Each memory phase uses two 25A/40A NexFETs, the CSD87350Q.

MSI X299 Gaming M7 ACK Circuit Analysis Continued

X299 Gaming M7 ACK Circuit Analysis Continued

MSI X299 Gaming M7 ACK Motherboard Review 28 | TweakTown.com

MSI is using a novel method of using two Realtek Codecs instead of one and a second amplifier. The method used here ensures that both the rear and front outputs offer 120dB with the integrated headphone amplifier in the ALC1220. Nichicon Gold Series audio capacitors and a fancy PCB divide offer enhancements to the motherboard's audio hardware.

MSI X299 Gaming M7 ACK Motherboard Review 29 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 30 | TweakTown.com

We find a Killer e2500 Gbit NIC for the wired LAN and a Killer Wireless AC 1535 controller for WIFI/BT.

MSI X299 Gaming M7 ACK Motherboard Review 31 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 32 | TweakTown.com

The rear IO panel uses an ASMedia ASM3142 controller and ASM1543 USB 3.1 type-C switch chip. The USB 3.1 internal header also uses an identical ASM3142 and ASM1543 to control the internal type-C header.

MSI X299 Gaming M7 ACK Motherboard Review 33 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 34 | TweakTown.com

ASMedia's ASM1074 takes one USB 3.0 port from the PCH and produces three USB 3.0 ports. One of the USB 3.0 ports uses an ASM1464 USB 3.0 re-driver to ensure USB 3.0 signal strength is strong at the rear of the motherboard.

MSI X299 Gaming M7 ACK Motherboard Review 35 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 36 | TweakTown.com

An ICS6V41742B is used to improve BCLK overclocking margins. The Renesas R5F104 microcontroller provides RGB LED control of the header and built in RGB LEDs on the motherboard.

MSI X299 Gaming M7 ACK Motherboard Review 37 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 38 | TweakTown.com

We get two 128Mbit/16MB BIOS ROMs for the BIOS, and a nuvoTon NCT5605Y GPIO extender enhances fan control. A nuvoTon NCT6795D provides SuperIO functions and offers the PS/2 on the rear IO.

MSI X299 Gaming M7 ACK Motherboard Review 39 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 40 | TweakTown.com

All of those ASMedia ASM1480s switch around PCI-E bandwidth. The LPC812 is an ARM microcontroller, it might be used for the BIOS flash recovery functionality.

BIOS and Software

BIOS

MSI X299 Gaming M7 ACK Motherboard Review 41 | TweakTown.com

MSI's X299 Gaming M7 ACK's UEFI is almost identical to that of their other X299 motherboards such as the Gaming Pro Carbon AC. It's very similar to MSI's other motherboards with both and Easy mode and a more advanced mode for experienced overclockers. I found that MSI has auto overlocking up to 5GHz on the 7900X (crazy), but I doubt you can do that without some sort of chiller.

Fan control has been improved over Z270, and now you have the ability to add more temperature sources for reference. MSI's overclocking settings are solid and plentiful, and you still have the ability to work in fixed or dynamic frequency mode.

MSI X299 Gaming M7 ACK Motherboard Review 42 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 43 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 44 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 45 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 46 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 47 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 48 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 49 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 50 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 51 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 52 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 53 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 54 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 55 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 56 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 57 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 58 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 59 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 60 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 61 | TweakTown.com
MSI X299 Gaming M7 ACK Motherboard Review 62 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 63 | TweakTown.com

Software

MSI X299 Gaming M7 ACK Motherboard Review 64 | TweakTown.com

Software includes MSI's APP Manager (which seems to replace Live Update in some sense), Mystic Light, Gaming APP, DPC Latency Tuner, Command Center, Fast Boot, Live Update 6, RAM Disk, Smart Rool, Super Charger, and X-Boost.

Test System Setup

Steven's Motherboard Test System Specifications

MSI X299 Gaming M7 ACK Motherboard Review 65 | TweakTown.com

I really like how aggressive and cool the RGB LEDs make the motherboard look. You can, of course, change the light color, but default is the color red.

MSI X299 Gaming M7 ACK Motherboard Review 66 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 67 | TweakTown.com

The heat sinks have built in RGB LEDs, and they diffuse light through the use of spacing and over-hanging plastic and metal. I really love the dragon, it lights up beautifully, and you will probably not want to put in a second GPU that blocks the PCH heat sink's dragon.

Overclocking

Overclocking Results

CPU Overclocking

MSI X299 Gaming M7 ACK Motherboard Review 68 | TweakTown.com

For the time being, I was testing how each motherboard can overclock the CPU and examining what settings to change to get a 4.6GHz overclock using AVX with XMP enabled. I enabled XMP, set OC mode to expert, increased frequency to x46, set input voltage at 1.75v, LLC to level 2, increased OCP, set VCore to 1.225v, and then rebooted without problem. The system was very stable.

Memory Overclocking

G.Skill TridentZ RGB 32GB (4x8GB) 3600MHz Kit:

MSI X299 Gaming M7 ACK Motherboard Review 69 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 70 | TweakTown.com

The board ran 3600Mhz on 32GB like a charm.

GEIL EVO SPEAR (4x8GB) 3200MHz Kit:

MSI X299 Gaming M7 ACK Motherboard Review 71 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 72 | TweakTown.com

GEIL's kit ran at 3200Mhz at 32GB with ease.

CPU, Memory, and System Benchmarks

CINEBENCH R15

MSI X299 Gaming M7 ACK Motherboard Review 73 | TweakTown.com

wPrime

MSI X299 Gaming M7 ACK Motherboard Review 74 | TweakTown.com

AIDA64 FPU

MSI X299 Gaming M7 ACK Motherboard Review 75 | TweakTown.com

AIDA64 Memory

MSI X299 Gaming M7 ACK Motherboard Review 76 | TweakTown.com

ScienceMark

MSI X299 Gaming M7 ACK Motherboard Review 77 | TweakTown.com

HandBrake

MSI X299 Gaming M7 ACK Motherboard Review 78 | TweakTown.com

SuperPi 32M

MSI X299 Gaming M7 ACK Motherboard Review 79 | TweakTown.com

3DMark: Fire Strike

MSI X299 Gaming M7 ACK Motherboard Review 80 | TweakTown.com

3DMark: Cloud Gate

MSI X299 Gaming M7 ACK Motherboard Review 81 | TweakTown.com

ResidentEvil 6

MSI X299 Gaming M7 ACK Motherboard Review 82 | TweakTown.com

The MSI X299 Gaming M7 is a solid performer without issues. The reason some of the numbers are lower in CINEBENCH and AIDA64 is because of microcode changes and a huge change in the performance numbers of Intel CPUs in the latest AIDA64 update. You can see the X299 Gaming i9 has the same thing going on, so there isn't an issue.

I don't too much too much credence into benchmarking the CPU or GPU to see how well the motherboard does, as the difference is almost always within the margin of error. These tests are to make sure performance isn't below that margin, or to see what's going on if it's above.

System IO Benchmarks

CrystalDiskMark SATA6G:

MSI X299 Gaming M7 ACK Motherboard Review 83 | TweakTown.com

CrystalDiskMark M.2:

MSI X299 Gaming M7 ACK Motherboard Review 84 | TweakTown.com

ixChariot Network Throughput:

MSI X299 Gaming M7 ACK Motherboard Review 85 | TweakTown.com

The X299 Gaming i9 has excellent SATA performance, but you might notice it's not included in the M.2 picture and that is because there seems to be an issue with my 950 Pro and the board. MSI is looking into it, but the board detects the drive in Windows, gives me very high sequential write and random 4K read and write numbers (the best I have seen so far), but odd sequential read numbers so I will test that later and update the chart. Networking performance is excellent, the wireless NIC rocks.

Audio RMAA 5.5:

I disable all audio features, set the correct bitrates, and then test the audio with a loopback test.

MSI X299 Gaming M7 ACK Motherboard Review 86 | TweakTown.com

Sound Judgment by Ear: Excellent, MSI has done an excellent job here. There are five ratings for audio: 1. Problems, 2. Okay, 3. Acceptable, 4. Very good, 5. Excellent

VRM and System Thermal Imaging and Power Consumption

Thermal Imaging and Power Consumption

System power is measured at the wall with an AC power meter.

MSI X299 Gaming M7 ACK Motherboard Review 87 | TweakTown.com

Note on Thermal Images: In the temperature section, we use our Seek thermal imaging camera to capture the surface temperatures of major components on the board. I look at the VRM and then all other things that light up the screen. If there is something to worry about, then I will state it. Otherwise, I will just show the hotter running parts of the board for fun. Unless some component is over 80-90C, then there isn't anything to worry about.

All systems will act differently, so I will look for commonalities, such as how far from the VRM the heat spreads through the PCB and the difference in temperature between the front side and backside of the PCB. Keep in mind, the majority of the heat from the VRM goes into the PCB as it is a giant soldered on copper heat sink. A larger difference in temperature between the back and front of the PCB points towards a more effective heat sink.

Thermal Testing at Stock Speeds:

The image on the left is always at idle, and the image on the right is at load. During ALL TESTS, fans above the VRM that cool the CPU cooler's (Corsair H110i) radiator are turned on to high (12v).

MSI X299 Gaming M7 ACK Motherboard Review 88 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 89 | TweakTown.com

Full frontal.

MSI X299 Gaming M7 ACK Motherboard Review 90 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 91 | TweakTown.com

Up-close of the front of the VRM.

MSI X299 Gaming M7 ACK Motherboard Review 92 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 93 | TweakTown.com

Up-close of the back of the VRM.

Performance is solid, not the craziest I have seen, but very good at stock. MSI is using very high-quality components, so this is expected.

Low to moderate airflow 4.6GHz 1.75V VCCIN OCed VRM Thermal Imaging:

MSI X299 Gaming M7 ACK Motherboard Review 94 | TweakTown.comMSI X299 Gaming M7 ACK Motherboard Review 95 | TweakTown.com

Temperature readings are taken after 40 loops of Intel Burn Test have been run (with AVX). Pictures of the setup are on the Test Setup Page. The two radiator fans (120mm Corsair) of the H110i blow in the general direction of the motherboard and VRM from the side (that is why the right side is slightly cooler in the first pic), so there is airflow (less than a case but more than a test bench with no airflow).

While the VRM on this motherboard is the same as that on the X299 Gaming Pro Carbon AC, the VRM temperature here are slightly better, and that could be a difference in ambient temperature, but it could also because of the copper content in the motherboard's PCB. From what I can tell, the motherboard's delta between back and front is also slightly better than on the X299 Gaming Pro Carbon.

What's Hot, What's Not & Final Thoughts

Here are key points about the MSI X299 Gaming M7 ACK.

What's Hot

Beautifully Bright: I really like how MSI has implemented their built-in RGB LEDs, but I also really respect how MSI has designed the motherboard to offer a totally black approach when it comes to allowing the motherboard to fade into a case. The was the RGB LEDs are diffused under the heat sinks and shields allows for a subtle yet recognizable design, and the dragon on the PCH heat sink is one of the most beautiful things I have seen on a motherboard.

M.2 Shield System: MSI has done a fine job with the M.2 shields. Both of them are attached by a strong hinge to the PCH heat sink, and a large thermal pad sits under each section of the shield to make great contact with the M.2 drive. The hinge mechanism is a nice touch; the only downside is that you have to remove your GPU to change or install M.2 drives.

The Latest USB Technologies: MSI offers both USB 3.1 on the rear and through an internal header on the inside of the motherboard, but they also offer both a right angled USB 3.0 internal header and a normal straight header. The rear of the motherboard also has a special USB 2.0 port that doubles as the port you can use for USB BIOS flash recovery.

OC Features: The OC Knob is a nice touch, but the POST code display, power button, reset button, and BIOS selection switch are also nice. The clear CMOS button on the back is nice. One thing that sticks out is the voltage read points, which isn't a common sight on X299 motherboards. MSI's BIOS settings also make overclocking very easy; I really like their fixed and dynamic frequency settings.

What's Not

Expensive: At almost $400 the X299 Gaming M7 ACK is one of the most expensive motherboards, and compared to many other X299 motherboards, it offers extra features to increase its price point. Whether you need those features is up to you.

Final Thoughts

MSI's X299 Gaming M7 ACK is not only sexy, but it's also loaded with features. I really like how the motherboard looks, and while MSI didn't go overboard with the RGB LEDs, they do offer some really nice LED effects, such as the dragon on the PCH. I am a huge fan of their new M.2 shield, and only one other brand has a solution I like to the same extent, and that solution is $100 more than this one.

MSI X299 Gaming M7 ACK Motherboard Review 96 | TweakTown.com

The quality on this motherboard is top notch, everywhere from the CPU and memory VRMs to the re-driver used on the USB 3.0 ports on the rear. I was also impressed with the Killer Wireless AC module and the dual audio codecs. The amount of metal in the PCH/M.2 heat sink is surprising, especially taking into account the amount of metal in the VRM heat sink.

MSI didn't cheap out when it comes to how the motherboard looks or how it performs, and it's a quality product with some stellar looks.

TweakTown award
Performance90%
Quality95%
Features91%
Value85%
Overall90%

The Bottom Line: With a really crazy custom M.2 shield mechanism, solid components in power delivery, and components to improve signaling, MSI's X299 Gaming M7 ACK is a quality product with fantastic looks to match.
