Eurocom launches MXM 3.0 AMD HD 6970M for graphics intensive embedded systems

Posted Apr 8, 2011 @ 2:25 CDT

urocom launches MXM 3.0 AMD HD 6970M for graphics intensive embedded systems

urocom_launches_mxm_3_0_amd_hd_6970m_for_graphics_intensive_embedded_systems_03

Eurocom Corporation (www.eurocom.com), the leading mobile technology developer launches the AMD HD 6970M MXM 3.0b graphics module for embedded systems. The AMD HD6970M graphics module is ideal for Eurocom embedded customers that require the absolute best in terms of graphical performance and processing. The module is also ideal for hardware designers developing small form factor PCs, embedded workstations and notebooks.

The industry standard MXM 3.0 specification for graphics subsystems allows for improved cooling capability, reduced power and height, enabling engineers to create smaller, more efficient embedded systems, reduce development time and costs and introduce new designs faster to market.

The HD 6970M graphics card is currently the highest performing card for embedded designs. Making it ideal for applications that require the highest possible graphics processing available, such as satellite imaging, mapping, surveillance, medical imaging, digital signage, image recognition, robotics, small form-factor computers, and notebook designs.

The graphics processor unit also supports 3D stereoscopic and BD-3D technologies with hardware MVC decode support. With the addition of the new security processor feature, DRM support can be off loaded from the CPU to GPU.

HD 6970M supports DX 11 with Shader Model 5.0, PCI E Revision 2.0, DisplayPort 1.2, and integrated HDMI 1.4a technologies. The unified Video Decoder 3 enables support for dual stream decode of high definition contents, along with the decode support of H.264 and VC-1, and entropy decode support of MPEG-2 HD and MPEG-4 part 2 (DivX and xVid).

-HD 6970M Product Details
Graphics Technology
-Mobility RADEON BLACKCOMB XT graphics technology

PCB Board
-Number of layers: 12
-Dimensions W x L: 105mmx82mm (4.13"x3.22")

Memory Configuration
-Onboard 2GB memory, 256-bits memory interface
-Memory clock: 900MHz
-Memory Bus Width: 256 bits
-Memory Type: 8pcs GDDR5 64MX32-5.0, Samsung K4G20325FC-HC04

Graphics ASIC
-ATI Radeon at 680Mz engine clock

Operating System Support
-Windows Vista
-Windows 7
-Linux

Display Support
-Register Compatible with VGA
-Supports VESA PnP compatible displays
-BIOS compatible with VESA for super VGA
-DDC 1/2b/2b+ monitor support
-VESA Display Power Management Support
-Separate horizontal and vertical synchronization at TTL levels
-HDCP ready

Display Support for VBios
-LVDS/DVI-D (single link)/ VGA

TDP: 75W

-Benchmarks HD 6970M
3DMark Vantage, 3D Mark 11, 3DMark 06, and Unigine Heaven 2.1.
3DMark Vantage: P 3420
3D Mark 11: P 13397
3DMark 06: 21043
Unigine Heaven 2.1: 680, 29.3 FPS

Full Benchmark Results: http://web.eurocom.com/ec/ec_GetBenchmarkB(2)

Tested in EUROCOM Racer
Processor: Intel i7-29320XM
Memory: 4G (2x2GB DDR3-1333)
Display: 15.6 inch Full HD, 1920x1080
Chipset: Intel HM 65


-About Eurocom

Eurocom is a leading developer of desktop replacement and mobile workstation technology. Eurocom began with the goal of creating the most advanced computer systems and using advanced engineering techniques typically unseen in the computer industry. The company has produced many firsts and continues to engineer well-balanced machines and VGA solutions that inspire and enable individuals to reach great possibilities.
For more information on programs, such as the "Trade in Program", "Education Program", "Factory Outlet" and "Upgrade Center" or to customize a machine, visit Eurocom.com.
