Intel's next-gen Z690 chipset has been spotted on a new prototype motherboard, at least according to a post on the Bilibili forums with someone uploading a photo of their prototype Intel Z690 motherboard.
The poster even says he's an "NDA War God" and while it shows the purported Intel Z690 motherboard, we have no additional information or details about the board from these photos. The board itself is a high-end variant, with up to 23 power stages around the CPU socket, which is normally here with high-end and enthusiast motherboards.
Intel's fresh new LGA1700 socket is shown here, with dual EPS connectors for the high-end board. We have 3 x M.2 connectors which is nothing new. I'm looking forward to the final form Z690 motherboards, which we'll see kick off later this year, and the bigger next-gen CPU fight between AMD and Intel in 2022 and beyond.
We know it's coming, but now it's a big step closer -- EVGA's new X570-based DARK series motherboard, which will take an AMD Ryzen CPU.
It has been 5 years since AMD unleashed the AM4 socket and now EVGA is crafting what should be one of the very best X570 motherboards ever made. A new teaser photo was posted by Vince "KINGPIN" Lucido, and I'd dare say if Vince is posting pictures of the EVGA X570S DARK motherboard, then we're not far from the announcement of the board.
But then there's a far bigger issue -- EVGA announced its Intel Z590-based DARK and FTW motherboards over 6 months ago now and they're still not available. So sure, EVGA could reveal its new X570S DARK motherboard any day or week now, but it could be the end of 2021 or even into 2022 before we see it in the flesh. Hopefully that's not the case.
ASUS has just announced a list of compatible motherboards that are ready for Windows 11 -- with the key player here being the TPM 2.0 (Trusted Platform Module) as it is a requirement of Windows 11.
ASUS updated their FAQ a couple of days ago to include a list of motherboards that are compatible with Windows 11, ready to rock and roll with TPM 2.0 and all. Before you begin, ASUS warns its users:
"Windows 11 has not been officially released and there might be stability issues with the Insider Preview build as it has not passed formal hardware validation and qualification. The installation or upgrade to the Windows 11 Insider Preview or any third-party software is done at your own discretion and risk. You will be solely responsible for any damage to your system or loss of data that results from that activity. ASUS will not be liable for any losses and damages in connection with the use of Windows 11".
BIOSTAR has announced which motherboards in its family of Intel and AMD motherboards supports Microsoft's next-gen Windows 11 operating system.
Windows 11 has full support from BIOSTAR and a particular list of motherboards that support the TPM 2.0 chip required for Windows 11, with TPM being the Trusted Platform Module. You need that to install and run Windows 11, and BIOSTAR is making the world know exactly which boards will work with Microsoft's next-gen OS.
BIOSTAR's range of Intel chipset-based motherboards: Z590, B560, B460, H510, B250 motherboards will be fine while on the AMD side of the fence we have support from BIOSTAR for Windows 11 with AMD chipsets that include the X570, B550, A520, X470, B450, X370, B350, and A320 series motherboards.
EVGA has been at the top of enthusiast motherboards for years now, but they've been totally absent from the AMD chipset world -- and that is all about to change:
The company teased "Darkness is coming" on Twitter, teasing that EVGA is working on a new DARK series motherboard with an AMD chipset -- presumably X570S (without the active chipset cooling). EVGA wasn't clear on what motherboard is coming, nor was the company clear about when its new DARK series motherboard would grace AMD Ryzen gamers.
Just as we're ramping up into the next-gen AM5 chipset and new Zen 4 architecture, EVGA has waited in the wings with what should be one of the most enthusiast level motherboards that money (will soon be able) to buy. AM4 is sticking around for a while it seems, and EVGA should have a truly kick ass Zen-ready X570/S motherboard.
We might not see this happen right away, but we're going to move away from that damn 24-pin power connector going into motherboards towards something far smaller, better, and more power-efficient.
Intel seems to be the one that is pushing for the new power-efficient ATX12VO power standard, with the launch of its upcoming 12th Gen Core "Alder Lake-S" platform. But the thing is: motherboard makers and PSU manufacturers aren't happy with the news.
It would mean a new 10-pin power connector on your motherboard -- so, a new motherboard. It would also mean a new 10-pin power connector ready on your new PSU, as the power supply can't feature any other power rails other than 12V. If voltage is lower or higher than 12V then it means the motherboard will be converting that power, and not the PSU like normal. Motherboards will be much more complex... costing more money... thus they are not happy about the move just yet.
If you want one of the ultimate PC gaming setups right now, you owe it to yourself to have GIGABYTE's new custom Z590 AORUS Xtreme Waterforce motherboard to be on your radar. Check it out:
GIGABYTE is using not just 1 but 2 different LED readouts that will not only look great, but they'll provide you with useful information like displaying the temperature of the water or the CPU. It's not just the read-outs though, as the huge monoblock takes over across a huge chunk of the board across both the Z590 chipset and those super-fast PCIe 4.0 NVMe M.2 SSDs as well.
It wouldn't be a motherboard that cost $1600 and had a gigantic monoblock if it didn't rock great power delivery, with GIGABYTE using 20+1 stage VRM with 100A power stages. You should be able to crank everything to the max when overclocking, with GIGABYTE even including built-in leak detection with its new Z590 AORUS Xtreme Waterforce motherboard. If a leak is detected, it will automatically shut down your entire PC.
Oh my word has MSI crafted something special with its new MEG Z590 ACE Gold Edition motherboard, which rocks actual 24K gold on its heat sink. Check it out:
The new MSI MEG Z590 ACE Gold Edition motherboard features a unique design, with an equally unique gold/silver/black theme throughout the board. MSI uses a direct 19-phase digital VRM with 90 Amp Smart Power Stages driven through 2 x 8-pin power connectors.
An actual genuine 24K gold foil heat sink is used, with platinum-colored parts scattered on top which would look fantastic in the right system alongside some G.SKILL Trident Z Royal RAM. We have an 8-layer PCB with 2oz Thickened Copper and support for up to DDR4-5600 RAM, so you should be good for overclocking. On top of that there's also dual Thunderbolt 4 ports and 4 x M.2 slots for a gigantic chunk of super-fast SSDs.
The next-gen ASUS Z690 motherboards are still a little while out but thanks to the latest version of HWiNFO, the software now includes support for the unreleased Z690 chipset and the ASUS ROG Maximus XIV family of motherboards.
Intel's next-gen LGA 1700 socket will be the star of the show on the Z690 motherboard, which will launch alongside and support the 12th Gen Core CPUs otherwise under the Alder Lake architecture. The new Alder Lake-S flagship CPU should end up being the Core i9-12900K -- and will work on the new Z690 chipset.
The new Alder Lake-S platform will also deliver PCIe 4.0 like Rocket Lake-S recently did, but we'll be getting some next-gen DDR5 memory and PCIe 5.0 support. The flagship Z690 chipset looks to be the only one that supports DDR5-4800 memory, while lower-end H670, B650, and H610 chipsets will support up to DDR4-3200 memory.
Russia has just unveiled its first B450 motherboard that is ready to take AMD Ryzen CPUs -- with Russia's CS Group and Philax announcing it is making "at least" 40,000 motherboards and 50,000 monitors.
The reason? Russia wants to lessen its reliance on securing products internationally, so making them in-house is the first step with the introduction of the new B450-based motherboards and 50,000 monitors on the way. The new motherboards might be under development still, but they've been passing all of the tests, certified for Russian government use, and can now be pre-ordered by certain clients in the country.
Philax used the ASRock B450M Pro4 because you can add a TPM module, a requirement for use by the government -- TPM or Trusted Platform Module, is a specialized chip on the motherboard that stores RSA encryption keys used by the system for hardware-based authentication.
