SilverStone Raven RV04 Chassis Detailed

Posted: May 10, 2013 6:25 am | Cases, Cooling & PSU Press Releases

Here are some of the first pictures of SilverStone's upcoming flagship chassis, the Raven RV04. Its styling is clearly evolutionary to the Raven RV03, with no chrome highlights, and a more curvy, "concave" front. The biggest change is on the inside, while the RV03 features a 90-degree clockwise-tilted motherboard tray, the RV04 uses an upside-down BTX-esque motherboard tray. Perhaps the new trend of detachable drive-bays to make room for long graphics cards caught up with SilverStone. The case supports ATX, E-ATX, and SSI-CEB motherboard form-factors.



silverstone_raven_rv04_chassis_detailed_07



silverstone_raven_rv04_chassis_detailed_08



silverstone_raven_rv04_chassis_detailed_09



The Raven RV04 features two 5.25-inch drive bays, seven internal 3.5-inch ones, of which two feature back-planes to enable hot-swapping; and four 2.5-inch bays. It features room for CPU coolers as tall as 165 mm, PSUs as long as 180 mm, and add-on cards as long as 337 mm, and as tall as 170 mm. Its front-panel includes two USB 3.0 ports (standard header), and audio jacks. Ventilation includes two gargantuan 180 mm front intake fans (up to 1200 RPM, up to 34 dBA), and a 120 mm rear fan. Measuring 219mm (W) x 581mm (H) x 497mm (D), the RV04 weighs about 11 kg. It's largely made of SECC steel and ABS plastic. It's available in two variants, one with the opaque side-panel (SST-RV04B), and one with an acrylic window (SST-RV04B-W). Pricing and availability will be announced on May 11.
